Specifications

Boja

Bela

Dimenzije

Φ109.9mm x 81mm

Fokusna daljina

2.8mm~3.6mm

Fokusni koeficijent

F1.6

Frame rate

704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps), 3.288 × 1.850@(1 ~ 20fps)/2.688 × 1.520@(1 ~ 25/30fps)

Interna

128MB

Masa

0.34kg

Mikrofon

Ugrađen

Mreža

ONVIF (Profile S&G&T)

Napomena

IK10 sertifikovano kućište otporno na oštećenja (vandalizam), IP67 sertifikovano vodootporno kućište, Metalno kućište, Operativna temperatura -40°C do +60°C, Wide Voltage

Ostalo

802.1x, Video encryption, configuration encryption, Digest, WSSE, account lockout, security logs, Generation and importing of X.509 certification, trusted boot, trusted execution, trusted upgrade, Firmware encryption, IP/MAC filtering, Syslog, Encrypted HTTPS

Osvetljenje

0 Lux sa Illuminator on, 0.0007Lux/F1.6 (crno-beli), 0.007Lux/F1.6 (u boji)

Podržane memorijske kartice

MicroSD (do 256GB), FTP, SFTP

Podržani audio formati

G.726, PCM, G.711a, G.711Mu

Podržani video formati

H.264, H.264B, H.264H, H.265, MJPEG, Smart H.264+, Smart H.265+

Protok žične mreže

10/100Mbps Base-T

Protokoli

IPv4, ARP, TCP, UDP, ICMP, RTSP, RTP, RTCP, IPv6, HTTP, FTP, NTP, SMTP, DNS, DDNS, PPPOE, DHCP, UPnP, IGMP, QoS, Bonjour, Multicast, NFS, SFTP, RTMP, P2P, Auto Registration, ONVIF, CGI

RAM

128MB

Reklamacioni period

24 meseca

Rezolucija senzora

6 Megapiksela

Rezolucija videa

1.280 x 720 (HD 720p), 1.920 x 1.080 (Full HD 1080p), 1.280 x 960 (1.3M), 704 x 576 (D1), 704 x 480 (D1), 640 x 480 (VGA), 352 x 288 (CIF), 352 x 240 (CIF), 2.304 x 1.296 (3M), 2.688 x 1.520 (4M), 2.048 x 1.536 (3M), 2.880 x 1.620 (5M), 3.200 x 1.800 (6M), 3.288 × 1.850 (6M)

Snimanje

Auto gain control, BLC, HLC, Detekcija pokreta, WDR, 3D NR, ROI, privacy masking, Manual gain control, Smart Illumination, Image Rotation, Mirror, Smart Dual Light, AWB, Ručni balans bele, BRC, Dan/noć (ICR)/Color/B/W, Perimeter Protection, SMD PLUS, Full-color

Tip kamere

WizSense

Tip kućišta

Dome

Tip senzora

CMOS

Uglovi snimanja

3.6mm: 110°×91°×46° (diagonal x horizontal x vertical), Pan: 0°–355°, Rotacija: 0°–355°, Tilt: 0°–65°, 2.8mm: 132°×112°×61° (diagonal x horizontal x vertical)

Veličina

1/2.7 inča
