Specifications

Boja

Bela

Dimenzije

122mm x 88.9mm

Fokusna daljina

2.8mm~12mm

Fokusni koeficijent

F1.7

Frame rate

704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps), 1.920 × 1.080@(1 ~ 25/30fps)

Interna

16MB

Masa

0.45kg

Mreža

ONVIF (Profile S&T)

Napomena

IK10 sertifikovano kućište otporno na oštećenja (vandalizam), IP67 sertifikovano vodootporno kućište, Metalno kućište, Operativna temperatura -40°C do +60°C, Wide Voltage, Cyber Security

Ostalo

Video encryption, configuration encryption, Digest, WSSE, account lockout, security logs, Generation and importing of X.509 certification, HTTPS, trusted boot, trusted execution, trusted upgrade

Osvetljenje

0 Lux sa IR on, 0.008Lux/F1.7 (u boji), 0.0008 Lux/F1.7 (crno-belo)

Podržane memorijske kartice

MicroSD (do 256GB), FTP

Podržani video formati

H.264, H.264B, H.265, MJPEG, Smart H.264+, Smart H.265+

Protok žične mreže

RJ-45 (10/100Mbps Base-T)

Protokoli

IPv4, ARP, TCP, UDP, RTSP, RTP, IPv6, HTTP, FTP, NTP, SMTP, DNS, DDNS, DHCP, Multicast, P2P, ONVIF, CGI, SDK, API, Milestone

RAM

128MB

Reklamacioni period

24 meseca

Rezolucija senzora

2 Megapiksela

Rezolucija videa

1.280 x 720 (HD 720p), 1.920 x 1.080 (Full HD 1080p), 1.280 x 960 (1.3M), 704 x 576 (D1), 704 x 480 (D1), 640 x 480 (VGA), 352 x 288 (CIF), 352 x 240 (CIF)

Snimanje

DWDR, BLC, HLC, Detekcija pokreta, 3D NR, ROI, privacy masking, Manual gain control, Smart Illumination, Image Rotation, Mirror, AWB, AGC, Ručni balans bele, BRC, Dan/noć (ICR)/Color/B/W, Detekcija lica

Tip kamere

HDCVI

Tip kućišta

Dome

Tip senzora

CMOS

Uglovi snimanja

101°~33.5° horizontalni, 52.5°~19° vertikalni, 125°–38.5° dijagonalni

Veličina

1/2.8 inča
